Spin your energy
Spin your energy. With the revolutionary wind propelled air compressor ALYSEO, Teseo is committed to saving the energy required for compressed air generation. Like electricity, compressed air is a fluid for energy transport, but more expensive – 10 times more expensive. Any factory or industry will be able to compensate compressed air losses in the production with the wind propelled compressor ALYSEO, without any electrical power supply.
Innovative
This innovative machine offers various advantages: it’s powered by a clean, free of charge renewable energy; it’sdesigned with a simple and economical technology; it’s not limited by wind direction; with the new wing profile air compression starts even with a light breeze. Energy is storable with air receivers under the form of compressed air; the entire structure is built in aluminum, 90% recyclable material.
Alyseo technical data
| Wind turbine with aluminium twisted blades | 3 blades |
|---|---|
| External diameter of the turbine | 13.12 ft |
| Orientation of the turbine | Self-directional rudder |
| Braking and blocking device | Electronic/Pneumatic |
| Maximum safe velocity | 55 ft/sec. (10 mph) |
| Volume of compressor air intake | 24.4 in³/revolution |
| Height of the support column | 21.3 ft. - 39.3 ft. |
| Maximum compressed air pressure (within safety limits) | 220 psi |
| Air produced with 19.6 ft./sec. wind speed (13.4 mph) | 2.4 cfm |
| Air produced with 26.2 ft./sec. wind speed (17.9 mph) | 3.2 cfm |
| Air produced with 32.8 ft./sec. wind speed (22.3 mph) | 4 cfm |
| Air produced with 39.3 ft./sec. wind speed (26.8 mph) | 4.8 cfm |
